NU-X NDD-3 Edge Mini Delay Pedal with 3 Modes

£7999
The RRP is the manufacturer's recommended retail price of the item.
Limited Stock
We are an Independent UK Company
Price match. Found it cheaper? Contact us
Trade Discount Available
Description

The NU-X NDD-3 Edge is a compact delay pedal (US: stompbox) with three switchable modes covering Phi Digital Delay, Analog Delay and Tape Echo. Phi Digital Delay gives a tapped repeat for a musical, rhythmic effect. Analog emulates bucket brigade device circuits, with repeats that soften and fade out gently. Tape Echo simulates the magnetic tape loop machines of the 60s and 70s for a more organic echo with tone-tempered repeats. You switch between all three using the illuminated push button above the controls.

Controls run to Time, Repeat and Mix, so you can shape each effect to suit the track. Pressing the footswitch engages or disengages the effect, and the smart tap tempo feature reads a quick double press of the footswitch to set the timing. Holding the mode button down during power-up chooses between mono and stereo output, with stereo needing a stereo jack lead. Between them, the three delay types cover a wide range of playing styles.

The chassis is aluminium die-cast, so it stays strong while keeping the weight down to 175g at 94 x 53 x 51mm. A USB-C port is fitted for future firmware updates. You can set buffered or true bypass to match your signal chain. The pedal runs on a 9V centre-negative DC supply with a 100mA current draw through a DC5521 connector; the adaptor is not supplied, and compatible power supply 173.290UK works with it.

Specification
Power supply 9Vdc (DC5521 connector, negative centre, adaptor not supplied)
Controls Time, Repeat, Mix and Phi Delay/Analog/Tape Echo switch
Dimensions 94mm x 53mm x 51mm
Weight 0.17KG
Downloads

Product Manual

Frequently Asked

What delay modes does the NDD-3 offer?

It has three switchable modes: Phi Digital Delay with a tapped repeat, Analog Delay with softly degrading repeats, and Tape Echo modelled on 60s and 70s tape machines.

Does it work in stereo?

Yes. Hold the mode button down during power-up to switch between mono and stereo output. Stereo output needs a stereo jack lead.

How do I set the tempo?

The smart tap tempo feature reads a quick double press of the footswitch and adjusts the Time setting to match your timing.

What power supply do I need?

A 9V centre-negative DC supply with a DC5521 connector and 100mA current draw. The adaptor is not supplied, but power supply 173.290UK is compatible.

Can I choose buffered or true bypass?

Yes. Both buffered and true bypass are selectable, so you can set it to suit your pedalboard and signal chain.

What is the USB-C port for?

The USB-C port is used for future firmware updates.
