Citronic TDCORVA-1215 Titanium HF Compression Driver

£2499
The RRP is the manufacturer's recommended retail price of the item.
Limited Stock
We are an Independent UK Company
Price match. Found it cheaper? Contact us
Trade Discount Available
Description

The Citronic TDCORVA-1215 is a high frequency compression driver built to power the horn flare of a high output PA cabinet. It uses a 75mm (3") Kapton voice coil mated to a 50mm titanium diaphragm, giving you the very high sound pressure levels that the upper frequencies demand in commercial sound reinforcement. With 150W rms power handling and a 300W maximum, it copes with the loads found in busy touring and installed systems.

This unit is a direct replacement for the CORVA-12 and CORVA-15 active or passive PA cabinets, so if you have blown a driver or want a spare on hand, it drops straight in. The 8 ohm impedance and 105dB/mW sensitivity make it an efficient match, and the frequency response runs from 800Hz to 20kHz, covering the range you need above the crossover point. The ceramic magnet weighs 1.75kg (62oz) and the whole driver comes in at 4.5kg.

The titanium diaphragm measures 140 x 110 x 30mm and weighs 40.3g, chosen for its accuracy and light weight so it responds quickly to signal detail. The 50mm (2") throat connects to standard horn flares, and the driver body measures 125 x 225mm. Whether you are servicing an existing rig or keeping stock for a hire fleet, this is a straightforward like for like part that keeps your cabinets working as intended.

Specification
Impedance 8 Ohm
Power handling : rms 150W
Power handling : max. 300W
Frequency response 800Hz - 20kHz
Diaphragm Titanium - 140 x 110 x 30mm, 40.3g
Sensitivity 105dB/mW
Voice coil 75mmØ (3") Kapton
Magnet Ceramic 1.75kg (62oz)
Throat 50mmØ (2")
Dimensions 125mm x 225mmØ
Weight 4.50KG
Frequently Asked

Which cabinets does this driver fit?

It is a direct replacement for Citronic CORVA-12 and CORVA-15 active or passive PA cabinets.

What is the power handling?

It handles 150W rms with a maximum of 300W, suited to high output sound reinforcement duties.

What impedance is the driver?

The impedance is 8 ohms, with a sensitivity of 105dB/mW.

What size is the throat?

The throat is 50mm (2"), which connects to standard horn flares.

What is the diaphragm made from?

The diaphragm is titanium, measuring 140 x 110 x 30mm and weighing 40.3g for a fast, accurate response.

What frequency range does it cover?

The frequency response runs from 800Hz to 20kHz, covering the high frequency range above the crossover.
