Description
The Adastra BC5A-B is a 2-way active stereo speaker set built around 5.25" drivers. It comes as a pair: one powered unit with a built-in stereo amplifier module, plus one passive satellite that connects to it. That layout keeps things simple, since you only need to run mains power to a single speaker and link the second one across with the supplied 4m cable.
Each channel puts out 30W RMS, so you get 2 x 30W across the pair. The drivers are magnetically shielded, which makes them suitable for placing near screens and monitors without picture interference. Front-mounted volume, treble and bass controls let you set the sound to the room, and there's a power on/off switch with an LED indicator so you can see at a glance when the set is live. The 133mm PP cone woofer handles the low end, while a 25mm balanced dome tweeter covers the highs, giving a frequency response of 100Hz to 20kHz.
We supply the set with mounting brackets, a 4m speaker link cable and a 1.5m figure-8 (fig.8) mains lead, so it's ready to install straight away. It suits nearfield monitoring, home entertainment or a small active background music system for a shop or office. Each unit measures 240 x 180 x 155mm and the pair weighs 4.6kg, with a sensitivity of 88dB and 150° dispersion at -3dB. Power comes from a 230Vac, 50Hz supply.
Specification
| Colour |
Black |
| Power supply |
230Vac, 50Hz (fig 8) |
| Woofer |
133mmØ (5.25") PP cone |
| Tweeter |
25mm balanced dome |
| Frequency response |
100Hz - 20kHz |
| Output power rms |
2 x 30W |
| Dispersion |
150° (-3dB) |
| Sensitivity |
88dB |
| Dimensions |
240mm x 180mm x 155mm |
| Weight (per set) |
4.60KG |
Downloads
Product Manual
Frequently Asked
Do I need a separate amplifier?
No. The powered unit has a built-in stereo amplifier module, so you just connect mains power and link the passive satellite across. No external amp is required.
What's included in the set?
You get one active and one passive speaker, mounting brackets, a 4m speaker link cable and a 1.5m fig.8 mains lead.
Can I place these near a TV or monitor?
Yes. The drivers are magnetically shielded, so they can sit close to screens without causing picture interference.
What power output do they deliver?
Each channel provides 30W RMS, giving 2 x 30W across the pair.
What size are the drivers?
Each speaker has a 133mm (5.25") PP cone woofer and a 25mm balanced dome tweeter.
What are they best used for?
They suit nearfield monitoring, home entertainment or a small active background music system in a shop or office.
