Description
This is a small square spotlight with an angled funnel, so the light leaves off to one side rather than dropping straight down. The face measures 93mm across, and the funnel is fixed at 45 degrees, which gives a set aim with no moving parts to work loose. It takes a GU10 lamp and the lampholder comes with it. We would fit a reflector LED in here, as the funnel is shaped around that sort of lamp.
Angled spotlights earn their keep where you want light on something rather than in the middle of the floor: a run of worktop, a bookcase, a picture, a brick chimney breast or a splashback. Set in a line, they wash a surface evenly and keep the ceiling quiet. Hallways and landings take them well too, aimed along one wall to draw the eye through. It will dim, provided the lamps you choose are dimmable and the dimmer you use is compatible with them.
The body is finished in plain white, so it sits quietly against a white ceiling and all but vanishes once the lamp is off. It is double insulated, and made for dry rooms indoors, which means kitchens, hallways and living spaces rather than a shower zone or an open porch. To clean it, wait until the lamp is cold, wipe the outer rim with a dry cloth, and lift dust from inside the funnel with a soft brush. It carries a two year warranty. The same square funnel is also offered in black, and we stock round versions of it in both white and black, plus flush square and round fittings in the range if you would rather the light came straight down. Lamps are not included.
Specification
| Colour |
White |
| Ceiling Mountable |
Yes |
| Wall Mountable |
Yes |
| Weight |
0.04KG |
| Length |
93mm |
| Width |
93mm |
| Height |
69mm |
| Cut Out |
85mm |
| Materials Used |
Polycarbonate |
| Energy Class |
A++ to B |
| Max Energy Class |
A++ |
| Min Energy Class |
B |
| Lamp |
1 x GU10 12W max (lamps not included) |
| Lamp Cap |
GU10 |
| Recommended Lamp |
LED (50mm Reflector) |
| Light Distribution |
Down |
| Protection Class |
Class 2 - Double Insulated |
| Total Power Consumption |
Dependent On Lamps Used (±5%) |
| Input Voltage |
100-240V~50/60Hz |
| Dimmable |
Yes - Dimmable Lamps Required |
| Dimmer Included |
No |
| IP Rating |
IP20 |
| Warranty |
2yrs |
| UKCA/CE |
Yes |
| Pieces Included |
1 |
| Installation |
Requires Installation By Qualified Electrician |
| Sloped Ceiling Compatible |
Yes |
| Sloped Ceiling Adapter Required |
No |
| Product Care |
(1) Wipe clean with a dry cloth, do not use any cleaning detergents, do not use rough or coarse material to clean. (2) Ensure light is not illuminated when cleaning. |
| Country of Origin |
China |
Frequently Asked
What lamp should I use with it?
A GU10 reflector lamp of 50mm diameter, up to a maximum of 12W. An LED is the sensible choice here, and lamps are supplied separately.
Can it be dimmed?
Yes, but only with dimmable GU10 lamps and a dimmer suited to them. No dimmer is supplied with the fitting.
How much room does it take up?
The visible face is 93mm square and the fitting stands 69mm deep behind it.
What does the 45 degree funnel actually do?
It angles the lamp so the beam is thrown to one side rather than vertically, which is what you want for lighting a wall, a worktop or artwork.
Is it suitable for a bathroom?
No. It is rated IP20, so keep it to dry rooms and leave bathroom zones to a fitting rated for moisture.
Is a lampholder included?
Yes, the GU10 lampholder is fitted as part of the spotlight.
