Description
The Asten is a slim rectangular LED bulkhead that delivers 1070 lumens from 12W of integrated LEDs, giving an efficiency of around 89 lm/W. Its 4000K cool white output sits between warm and daylight, a clean neutral tone that suits practical spaces. The wide 120 by 105 degree spread washes light evenly across the surface it is mounted to rather than throwing a tight beam, so it lights an area broadly and without glare. In US terms a fitting of this style is often called a wall pack or outdoor wall sconce, used where a compact surface light is needed on a wall or low ceiling.
Measuring 600mm long and just 42mm deep, the Asten works well in entrance halls, stairwells, utility rooms and along corridors where a low-profile linear fitting suits the wall line. Its IP44 splash rating means it is also at home in sheltered outdoor spots such as a porch, carport or covered passage, and in bathroom zones away from direct water. Rather than acting as a room's main ambient source, it provides reliable surface and circulation lighting, marking a doorway, lighting a path of travel or adding even illumination to a wall run. The broad beam keeps the light soft across the area it covers.
Built from aluminium alloy with a white finish, the Asten is a robust integrated fitting that weighs only 270g and carries a rated lifespan of 25,000 hours. It is surface mounted directly to the wall and runs from a standard 220 to 240V AC mains supply, with no separate transformer required. This version is not dimmable, so it switches on at its full 1070 lumen output. The IP44 sealing keeps out splashes and dust ingress for use in damp and sheltered locations. Other tones and sizes are available within the Asten range if you need to match fittings across a project.
Specification
| Power |
12W |
| Voltage |
220-240 AC |
| Luminous flux |
1070 lm |
| Efficiency |
89 lm/W |
| Colour temperature |
4000K |
| Colour rendering (CRI) |
Ra 80 |
| Beam angle |
X120/Y105° |
| IP rating |
IP44 |
| Dimmable |
No |
| Mounting |
Wall Mounted |
| Lifespan |
25,000 hours |
| Shape |
Rectangular |
| Dimensions |
600 × 110 × 42 mm |
| Weight |
270 g |
| Material |
Aluminium Alloy |
| Finish |
White |
Downloads
Frequently Asked
Can the Asten be used outdoors?
It carries an IP44 rating, which protects against splashing water and makes it suitable for sheltered outdoor spots such as a porch, carport or covered entrance. It should be kept clear of fully exposed positions, direct water jets or anywhere it could be submerged. For damp indoor areas and bathroom zones away from direct water it works well.
Does it take a separate bulb?
No, the Asten uses integrated LEDs rather than a replaceable lamp, so there is no bulb to fit or change. The 12W LED array is built in and rated for around 25,000 hours of use. When the unit reaches the end of its life the whole fitting is replaced.
Where is this fitting typically used?
Its slim 600mm rectangular form suits entrance halls, stairwells, corridors, utility rooms and porches where a compact surface light is needed. The 4000K cool white tone gives clear, neutral light for circulation and practical areas. It can be mounted on a wall or low ceiling.
How do I clean and maintain it?
Wipe the white aluminium body and diffuser with a soft, dry or slightly damp cloth, avoiding abrasive cleaners that could mark the finish. Make sure the fitting is switched off and cool before cleaning. Keeping the diffuser clear of dust helps maintain the full 1070 lumen output.
