Description
The DAXA-M-IR is a slim rectangular LED ceiling light running at 9W and pushing out up to 640 lumens, with switchable colour selectable output across 3000K, 4000K and 5500K so the same fitting can read warm, neutral or cool to suit the space. Built around an integrated LED rather than a replaceable lamp, it carries an infrared presence sensor that brings the light on automatically when movement is detected. In the United States a low-profile fitting of this kind sits in the flush mount led ceiling light category, and the 280mm body keeps it close to the surface whether wall or ceiling mounted.
Sized as it is, the DAXA-M-IR works well as task and transit lighting in places where hands-free switching earns its keep: hallways, landings, stairwells, utility cupboards and walk-in storage. At general lighting levels its 640 lumens cover around 2 m², so it suits a single focused zone or a short run of fittings stepped along a corridor rather than a whole open room. Because it is integrated and sensor-driven, mount it where the detection field reads people approaching, and on standard ceiling heights it gives even, shadow-free coverage directly below.
The housing is aluminium alloy in a white finish, rectangular at 280 by 60 by 9.2mm and weighing just 168g, so it sits discreetly against the surface. It runs on 24V DC and is not dimmable, with the colour temperature chosen at the fitting rather than via a dimmer. The IP20 rating means it is for dry indoor use only, so keep it clear of bathrooms, porches and any exposed location. Rated efficiency reaches 128 lm/W with a 35,000 hour lifespan and Ra 80 colour rendering. Mounting hardware lets it fix to wall or ceiling, and the wider DAXA-M-IR range offers further options for matching a scheme.
Specification
| Power |
9W |
| Voltage |
24 DC |
| Luminous flux |
max 640 lm |
| Efficiency |
max 128 lm/W |
| Colour temperature |
3000/4000/5500K |
| Colour rendering (CRI) |
Ra 80 |
| IP rating |
IP20 |
| Dimmable |
No |
| Mounting |
Wall Mounted, Ceiling Mounted |
| Lifespan |
35,000 hours |
| Shape |
Rectangular |
| Dimensions |
280 × 60 × 9.2 mm |
| Weight |
168 g |
| Material |
Aluminium Alloy |
| Finish |
White |
Downloads
Frequently Asked
How big a space does this light cover?
At general lighting levels its 640 lumens cover around 2 m², which makes it well suited to a single focused area such as a hallway, landing or cupboard. For longer corridors, use several units stepped along the run rather than relying on one. It works as task and transit lighting rather than as the main light for a large open room.
Does it use a replaceable bulb?
No, the DAXA-M-IR has an integrated LED built into the fitting, so there is no separate bulb to change. The LED array is rated for 35,000 hours of use. When the diodes eventually reach the end of their life you replace the whole unit rather than a lamp.
Can the light be dimmed or its colour changed?
It is not dimmable, so it should not be wired to a dimmer switch. It does offer switchable colour selectable output across 3000K, 4000K and 5500K, letting you set a warm, neutral or cool white to suit the room. The tone is chosen at the fitting itself.
How do I clean the fitting?
Wipe the white aluminium body and the lit surface with a soft, dry or slightly damp cloth, with the power switched off and the fitting cool. Avoid abrasive pads and harsh solvents, which can mark the finish. As it is rated IP20 for dry indoor use only, never let water run into the housing.
