10A Triple Pole Fan Isolator Module - Brushed Chrome

£699
The RRP is the manufacturer's recommended retail price of the item.
Limited Stock
We are an Independent UK Company
Price match. Found it cheaper? Contact us
Trade Discount Available
Description

The Knightsbridge 10A fan isolator module is a triple-pole switching insert designed to fit grid mounting frames (sold separately). The module controls bathroom extractor fans, kitchen extract fans and utility room ventilation, providing a dedicated isolator that cuts power to the fan circuit independently of lighting circuits. The triple-pole design breaks live, neutral and switched-live connections when the switch is moved to the OFF position.

Designed for installation in UK residential bathrooms, kitchens and utility rooms, the module clips into Knightsbridge grid frames from the front once the frame is fixed to the wall. This front-loading method allows multiple modules to be combined in a single plate without removing the frame or re-wiring. The 25mm minimum back box depth suits standard UK wiring installations, and the IP20 rating confirms safe use in Zone 3 bathroom areas (more than 600mm from the bath or shower edge).

The brushed chrome faceplate has a linear grain finish that softens reflections and pairs with both contemporary and industrial interiors. The rocker switch is engraved with OFF/ON and 'FAN isolator' text for clear identification. The module is rated for 10A at 230V 50Hz, which covers all standard domestic fan loads, and carries a conditional short circuit current rating of 1500A (Inc) for compliance with wiring regulations.

Specification
Height 56.3 mm
Width 25 mm
Projection 7 mm
Recessed Depth 12 mm
Min. Mounting Box Depth 25mm
Construction ABS
Construction 2 & steel
Finish Brushed Chrome
IP Rating IP20
Primary Voltage 230V 50Hz
Warranty 25
Downloads

Product Specification Sheet

Frequently Asked

What is a triple-pole fan isolator?

A triple-pole isolator breaks three connections when switched off: live, neutral, and switched-live. This fully isolates the fan circuit from mains power, allowing safe maintenance or fan replacement without needing to isolate the entire lighting circuit at the consumer unit.

Does this include the mounting frame?

No. The module clips into Knightsbridge grid mounting frames, which are sold separately. You will need to select a frame that matches the number of modules you want to install (1-gang, 2-gang, 3-gang or 4-gang frames are available).

Can it be installed in a bathroom?

Yes, with IP20 rating this module is safe for Zone 3 bathroom installation (more than 600mm from the edge of the bath or shower). It cannot be installed in Zones 0, 1 or 2.

What other finishes are available in this range?

Knightsbridge produces grid modules in multiple finishes including polished chrome, matt black, white, polished brass and stainless steel. Use the site search or filters to find other variants in stock at Niori.
