Description
This is the widest of the Cabrera round downlights, a broad matt white face that recesses into the ceiling and throws a wide, soft wash rather than a narrow beam. The integrated LED draws 30W and runs at 4000K, a clean neutral white that keeps colours honest and worktops looking crisp. Its driver is supplied with it. There is no dimming, so an ordinary switch is all it asks for.
At 300mm across, it covers a good deal of floor from a single point, which is handy in rooms where you would rather not pepper the ceiling with small fittings. We use it in kitchens, utility rooms and workshops, and it earns its place on a wide landing or in a hall where the ceiling is high enough to spread the light out. The neutral white suits task areas, so think food prep, laundry, ironing and desk work rather than a quiet corner for reading in the evening. Keep it to dry rooms indoors.
The body is shallow and double insulated, and the matt white finish is flat enough not to catch reflections or show a bright edge when you look up at it. Dust settles on a pale trim, so give the visible rim an occasional pass with a dry cloth once the fitting has cooled, and leave solvents and sprays out of it. It carries a three year warranty. The LED is built in, so there is no separate lamp to source. Within the range we stock the same round shape in smaller diameters, and this size again in a warmer white if you want something gentler overhead.
Specification
| Colour |
Matt White |
| Ceiling Mountable |
Yes |
| Recessable |
Yes |
| Weight |
0.98KG |
| Diameter |
300mm |
| Height |
63mm |
| Cut Out |
285mm |
| Materials Used |
Die-cast Aluminium |
| Energy Class |
F |
| Energy Class of Lamp |
Group A |
| Max Energy Class |
F |
| Min Energy Class |
F |
| Lamp |
1 x 30W integrated LED (no lamps to fit) |
| Lamp Cap |
Integral LED |
| Recommended Lamp |
Integral LED |
| Colour Temperature |
4000K Cool White (±5%) |
| Number of Switching Cycles |
30000 |
| Average Life of LED |
20000hrs |
| LED Brand |
Epistar |
| Qty of SMD |
144 |
| SMD Chipset |
2835 |
| LED Power |
0.2W (±5%) |
| Type of LED |
SMD |
| Lumens per LED |
26-28lm |
| Lumens per Watt (lm/W) |
87lm/W (±5%) |
| Beam Angle |
171° |
| System Flux |
2600lm (±5%) |
| CRI |
>80 |
| Light Distribution |
Down |
| Driver Included |
Yes |
| Type of Driver |
Constant Current |
| Constant Current Output |
700mA |
| Min/Max. Voltage Output |
25-42V |
| Load Range |
30W |
| Ta |
50°C |
| Tc |
85°C |
| Casing Material |
Aluminium |
| Protection Class |
Class 2 - Double Insulated |
| Total Power Consumption |
30W (±5%) |
| Input Voltage |
220-240V~50/60Hz |
| Dimmable |
No |
| IP Rating |
IP20 |
| Warranty |
3yrs |
| UKCA/CE |
Yes |
| TUV |
Yes |
| EMV/EMC |
Yes |
| Pieces Included |
1 |
| Installation |
Requires Installation By Qualified Electrician |
| Sloped Ceiling Compatible |
Yes |
| Sloped Ceiling Adapter Required |
No |
| Product Care |
(1) Wipe clean with a dry cloth, do not use any cleaning detergents, do not use rough or coarse material to clean. (2) Ensure light is not illuminated when cleaning. |
| Country of Origin |
China |
Frequently Asked
How much light does it give out?
It produces 2600 lumens from 30W, at a neutral 4000K. That is enough to serve as the main light in a small kitchen or utility room, or to work alongside one or two others across a bigger space.
What size opening does it need?
The cut-out is 285mm and the outer face measures 300mm in diameter, so the trim covers the edge of the opening. The body is 63mm deep behind the face.
Can I put it on a dimmer switch?
No. This one is non-dimmable and should be run from a standard on/off switch. Using it with a dimmer can cause flicker and shorten the life of the electronics.
Is it suitable for a bathroom or a covered porch?
It is rated IP20, so it belongs in dry indoor rooms. For a bathroom zone or anywhere exposed to damp, choose a fitting with a higher protection rating.
How do I clean the white face?
Switch off at the wall and let it cool, then wipe the rim and lens with a soft dry cloth. Avoid solvents, abrasive creams and aerosol polishes, which can dull a matt finish.
Does it need a separate driver?
No, the driver is included with the fitting, and the LED is integral rather than a replaceable lamp.
