13A Fused Spur Unit - Brushed Chrome Screwless

£899
The RRP is the manufacturer's recommended retail price of the item.
Limited Stock
We are an Independent UK Company
Price match. Found it cheaper? Contact us
Trade Discount Available
Description

The Knightsbridge 13A fused spur unit provides a switched connection point for fixed appliances such as boilers, extractor fans, water heaters and kitchen appliances, with the fuse accessible behind a brushed chrome screwless faceplate. The cover plate clips onto a separate metal sub-frame, hiding all fixings for a clean finished appearance on the wall.

Designed for residential and commercial installation where a permanently wired appliance needs its own dedicated circuit protection, the unit accepts a standard 13A fuse cartridge which can be replaced without disconnecting the wiring. The built-in gasket between the sub-frame and the cover plate reduces dust ingress and provides a firm seating for the faceplate. The 25mm minimum back box depth requirement makes it compatible with standard UK back boxes in both new-build and retrofit applications.

The brushed chrome finish is a fine linear grain that softens reflections compared to polished chrome, pairing well with contemporary kitchens, bathrooms and utility rooms where stainless steel appliances or chrome taps are already present. The 87.5mm square faceplate matches the dimensions of standard UK single-gang plates, allowing it to sit in line with adjacent switches and sockets from the same Knightsbridge range. The unit is certified to BS 1363-4 and carries a 25-year manufacturer warranty.

Specification
Height 87.5 mm
Width 87.5 mm
Projection 4.3 mm
Min. Mounting Box Depth 25mm
Construction Premium grade steel
Finish Brushed Chrome
Class I
IP Rating IP20
Primary Voltage 230V 50Hz
Earth Terminal Yes
Neon Indicator No
Warranty 25
Downloads

Product Specification Sheet

Product Manual

Frequently Asked

What appliances is a fused spur unit used for?

Fused spur units provide a switched connection point for fixed appliances such as boilers, extractor fans, water heaters, electric towel rails, and hardwired kitchen appliances. They allow the appliance to be isolated for servicing without needing to access the consumer unit.

Can the fuse be replaced without disconnecting the wiring?

Yes. The fuse holder is accessible by removing the screwless cover plate, which clips off the sub-frame without disturbing the terminal connections. The unit accepts a standard 13A fuse cartridge.

What back box depth is required?

A 25mm minimum back box depth is needed for safe installation. The screwless cover plate adds approximately 4.3mm of projection from the wall once fitted.

Is the screwless plate removable for redecorating?

Yes. The brushed chrome cover plate clips onto a separate metal sub-frame fixed to the back box. The cover can be removed for painting around the unit and re-clipped without re-wiring.
