Description
The QTX Q1000 is a stereo power amplifier built to work hard in venues, for DJs and for live performers. It delivers 2 x 500W across two channels, giving you the headroom to drive a pair of passive speakers with plenty of level to spare. We designed it as a reliable workhorse, so it holds up to regular use without fuss.
Connections are flexible at both ends. On the input side you get 6.3mm jack (also called a quarter-inch jack) or RCA (phono) sockets for the left and right channels, with an input sensitivity of 775mV at 10k Ohms. Outputs cover SPK connectors, 6.3mm jack and 4mm binding posts, so you can wire it into most speaker setups. Frequency response runs from 20Hz to 20kHz, with a signal-to-noise ratio over 98dB and THD under 0.5%.
The Q1000 is fan cooled to keep temperatures in check during long sessions, and it fits a standard 19-inch rack at 2U high. Power comes from a 230Vac, 50Hz IEC mains supply, so it slots straight into UK rig setups. This is part of the QTX Q Series range of stereo power amplifiers, giving you a straightforward, dependable amp for accurate playback night after night.
Specification
| Power supply |
230Vac, 50Hz (IEC) |
| Frequency response |
20Hz - 20kHz |
| Input connectors |
6.3mm jack, RCA (L+R) |
| Input sensitivity |
775mV, 10k Ohms |
| Output connectors |
6.3mm jack, SPK, 4mm binding posts (L+R) |
| S/N ratio |
>98dB |
| THD |
<0.5% |
Downloads
Product Manual
Frequently Asked
How much power does the Q1000 deliver?
It delivers 2 x 500W across its two stereo channels, giving plenty of headroom for driving passive speakers in venues and live setups.
What inputs and outputs does it have?
Inputs are 6.3mm jack (quarter-inch jack) or RCA (phono) for left and right. Outputs include SPK connectors, 6.3mm jack and 4mm binding posts.
Will it fit a standard rack?
Yes. The Q1000 is 19-inch rack-mountable and takes up 2U of rack space.
How is it kept cool?
It uses fan cooling to manage heat during extended use, which helps it stay reliable through long sessions.
What are the audio performance figures?
Frequency response runs 20Hz to 20kHz, signal-to-noise ratio is over 98dB and total harmonic distortion is under 0.5%.
What power supply does it need?
It runs from a 230Vac, 50Hz mains supply via an IEC connector, suited to UK use.
