Citronic D4500 Quad Class-D Power Amplifier 4 x 500W

£49999
The RRP is the manufacturer's recommended retail price of the item.
Limited Stock
We are an Independent UK Company
Price match. Found it cheaper? Contact us
Trade Discount Available
Description

The Citronic D4500 is a quad digital power amplifier built into a lightweight 1U rack-mountable case. It uses an energy-efficient switch-mode power section and a class-D amplifier circuit to deliver power on demand across four independent speaker outputs. Proprietary cool guide technology keeps the temperature stable for dependable operation, whether the unit sits in a permanent install or goes out on the road.

You can run the D4500 as a quad, stereo or 2.1 system, and each pair of output channels can be parallel switched or bridged. Channel A has a switchable 120Hz low-pass filter (LPF) for use with subwoofers, while channels C and D share a switchable stereo pair of 120Hz high-pass filters (HPF) to focus power in full-range cabs working as mid-tops alongside subs. The audio signal path is fully balanced, with four female XLR inputs and four Speakon-style SPK outputs.

Full audio and power protection is built in, including a peak limiter to guard both the amplifier and the connected speakers. Input sensitivity is set at 0dB = 0.775Vrms, and the unit runs from a standard 220-240Vac IEC mains supply. For audio designers and sound engineers, the D-series is a flexible problem solver that adapts to a wide range of speaker configurations without taking up much rack space.

Specification
Power supply 220-240Vac, 50/60Hz (IEC)
Modes 2 x Stereo, Parallel (mono), Bridge (mono)
Input sensitivity 0dB = 0.775Vrms
Input connections 4 x XLR female
Sound output 4 x SPK connectors
Crossover Input A 120Hz LPF and C+D 120Hz HPF (all switchable)
Frequently Asked

How much power does the D4500 deliver?

It provides four channels at 500Wrms each. Channels can be bridged in pairs to increase output for a single speaker load.

What speaker setups does it support?

You can configure it as a quad, stereo or 2.1 system. Each pair of output channels can be run in parallel mono or bridged mono.

What connections does it use?

There are four female XLR inputs and four SPK (Speakon-style) speaker outputs. Mains is a standard IEC input at 220-240Vac.

Does it have built-in crossovers?

Yes. Channel A has a switchable 120Hz low-pass filter for subwoofers, and channels C and D have switchable 120Hz high-pass filters for mid-top cabs.

How much rack space does it take?

The D4500 fits a single 1U rack slot and is lightweight thanks to its switch-mode power supply and class-D design.

Is it protected against overload?

Yes. It includes full audio and power protection with a peak limiter, plus cool guide technology for stable temperature management.
