Description
The Frame is a surface-mounted ceiling light built as an open square metal border that draws a clean outline on the ceiling, with the light held in a band set inside the outer edge. An integrated LED sits behind an opal plastic diffuser and throws its glow straight down, so the lit portion reads as a soft warm 2700K ribbon rather than a single bright point. Unlit, the piece stays graphic and quiet, a plain white square drawn flat overhead.
This square form measures 533mm by 558mm and stands 58mm from the ceiling, giving 4000 lumens from a 33W LED with a CRI above 90 so colours in the room read true. Its shape suits a living room, bedroom or study as the main light, and it pairs with the round and rectangular Frame shapes where a matching set across rooms is wanted.
The base and border are matt white varnished metal, with the light behind an opal plastic diffuser, rated IP20 for dry indoor rooms. The driver is built in and the LED is rated near 30,000 hours, so there is nothing to buy or replace after fitting. We supply it as an on/off ceiling light wired straight to the mains.
Specification
| Number of lights |
1 |
| Light source |
Integrated LED, 33W total (4000lm, 30,000h, CRI >90, bulbs included) |
| Colour temperature |
2700K (warm white) |
| Width |
533mm (533 x 558mm square form) |
| Height |
58mm |
| IP rating |
IP20 |
| Dimmable |
No (on/off) |
| Frame / Structure finish |
Matt white metal |
| Diffuser |
Opal plastic |
| Materials |
varnished metal base and border, opal plastic diffuser |
Downloads
Datasheet
Assembly Instructions
3D Model
Frequently Asked
What kind of light does the Frame give?
A soft warm 2700K glow thrown downward from a band set inside the border. The integrated LED sits behind an opal plastic diffuser, giving 4000 lumens as an even wash rather than a hard central point, with a CRI above 90 so colours look true.
Does it need bulbs?
No. The Frame carries an integrated 33W LED, so the source is built in and included. There are no lamps to fit, and the diode is rated for around 30,000 hours of use.
Is it dimmable?
As supplied it is a plain on/off fitting and not stated as dimmable. We would treat it as fixed output unless a compatible dimming setup is confirmed, and we can advise before you order.
How big is it and where does it suit?
The square form is 533mm by 558mm and sits 58mm below the ceiling. It works as the main light in a living room, bedroom or study, and matches the round and rectangular Frame shapes for a set across rooms.
