Description
The Frame is a surface-mounted ceiling light built as an open rectangular metal border that draws a clean outline on the ceiling, with the light held in a band set inside the outer edge. An integrated LED sits behind an opal plastic diffuser and throws its glow straight down, so the lit portion reads as a soft warm 2700K ribbon rather than a single bright point. Unlit, the piece stays graphic and quiet, a plain white outline drawn flat overhead.
This rectangular form measures 625mm by 410mm and stands 60mm from the ceiling, giving 3500 lumens from a 33W LED with a CRI above 90 so colours in the room read true. Its long shape suits a dining table, kitchen island or hallway as the main light, and it pairs with the round and square Frame shapes where a matching set across rooms is wanted.
The base and border are matt white varnished metal, with the light behind an opal plastic diffuser, rated IP20 for dry indoor rooms. The driver is built in and the LED is rated near 30,000 hours, so there is nothing to buy or replace after fitting. We supply it as an on/off ceiling light wired straight to the mains.
Specification
| Number of lights |
1 |
| Light source |
Integrated LED, 33W total (3500lm, 30,000h, CRI >90, bulbs included) |
| Colour temperature |
2700K (warm white) |
| Width |
625mm (625 x 410mm rectangular form) |
| Height |
60mm |
| IP rating |
IP20 |
| Dimmable |
No (on/off) |
| Frame / Structure finish |
Matt white metal |
| Diffuser |
Opal plastic |
| Materials |
varnished metal base and border, opal plastic diffuser |
Downloads
Datasheet
Assembly Instructions
3D Model
Frequently Asked
What kind of light does the Frame give?
A soft warm 2700K glow thrown downward from a band set inside the border. The integrated LED sits behind an opal plastic diffuser, giving 3500 lumens as an even wash rather than a hard central point, with a CRI above 90 so colours look true.
Does it need bulbs?
No. The Frame carries an integrated 33W LED, so the source is built in and included. There are no lamps to fit, and the diode is rated for around 30,000 hours of use.
Is it dimmable?
As supplied it is a plain on/off fitting and not stated as dimmable. We would treat it as fixed output unless a compatible dimming setup is confirmed, and we can advise before you order.
How big is it and where does it suit?
The rectangular form is 625mm by 410mm and sits 60mm below the ceiling. Its long shape works over a dining table, kitchen island or hallway, and matches the round and square Frame shapes for a set across rooms.
