QTX MM41 4-Channel Mono Mini Microphone Mixer

£2999
The RRP is the manufacturer's recommended retail price of the item.
Limited Stock
We are an Independent UK Company
Price match. Found it cheaper? Contact us
Trade Discount Available
Description

The QTX MM41 is a compact mono microphone mixer with four low impedance jack inputs, all mixing down to a single master jack output. It gives you a simple way to combine several microphones without a large desk taking up space, so it suits small venues, meeting rooms, houses of worship and portable setups where you just need a few mics running through one output.

Each of the four channels has its own volume control, with a separate control for the master output. That means you can balance the level of each microphone and then set the overall level from one place. The inputs run at 3.3k Ohms impedance and the master output is 600 Ohms on a single 6.3mm (quarter-inch) jack, so it connects easily to an amplifier or powered speaker. If you need more inputs, the range also includes an eight channel version.

Power comes from a single 9V PP3 battery, which is not supplied, or you can use an optional 12Vdc 200mA power adaptor for fixed installations. The battery option keeps things portable and useful where mains power is awkward to reach. The unit measures 150 x 108 x 64mm, so it fits neatly on a desk, a shelf or into a bag. It is a practical, no-fuss mixer for anyone who needs to bring a handful of microphones together into one clean feed.

Specification
Battery 9V battery (PP3 - not supplied)
Input impedance 3.3k Ohms
Output impedance 600 Ohms
Output : master 1 x 6.3mm jack
Dimensions 150mm x 108mm x 64mm
Power adaptor 12Vdc, 200mA (optional)
Downloads

Product Manual

Frequently Asked

How many microphones can I connect?

The MM41 has four low impedance jack inputs, so you can connect up to four microphones. An eight channel version is also available in the range if you need more.

Is this a mono or stereo mixer?

It is a mono mixer. All four channels mix down to a single master output on a 6.3mm jack.

How is the MM41 powered?

It runs on a single 9V PP3 battery, which is not supplied, or an optional 12Vdc 200mA power adaptor for mains use.

What output connector does it use?

The master output is a single 6.3mm (quarter-inch) jack, so it connects to most amplifiers and powered speakers.

Can I control the volume of each microphone separately?

Yes. Each channel has its own volume control, plus a separate control for the master output level.

What size is the unit?

It measures 150 x 108 x 64mm, so it fits easily on a desk, shelf or into a bag.
