Trinity Track Lighting Live L-Connector - White

£999
The RRP is the manufacturer's recommended retail price of the item.
Limited Stock
We are an Independent UK Company
Price match. Found it cheaper? Contact us
Trade Discount Available
Description

The Trinity is a live L-connector for single-circuit track lighting systems, designed to join two track sections at a 90-degree angle while maintaining continuous power feed through both runs. The connector body is moulded from white plastic with brass contact pins that align with the internal conductors in compatible track profiles.

Used in residential and commercial track lighting installations where the track needs to turn a corner around a room perimeter, along kitchen peninsulas, or across open-plan living spaces. The live connector allows spotlights and pendants to be positioned anywhere along both arms of the L-shaped run without requiring a separate power feed at the corner. The white finish integrates cleanly with white-painted ceilings and matches the standard white finish on track profiles.

The connector slots into the track channel and locks with a quarter-turn mechanism, similar to how individual track heads are fitted. Once installed, the connector body sits flush with the track profile and provides a stable mechanical and electrical joint rated for 220-240V 50Hz AC supply. The IP20 rating suits dry indoor environments - kitchens, living rooms, retail spaces and galleries - but not bathrooms or outdoor installations.

Specification
IP Rating IP20
Voltage 220-240V 50Hz AC
Dimmable No
Material Plastic
Finish White
Downloads

Product datasheet

Frequently Asked

What track systems is this compatible with?

The Trinity is designed for single-circuit track systems. Check that your existing track profile matches the range before purchasing. The connector will not fit tracks from other manufacturers due to variations in channel width and contact pin positioning.

Does it carry power through both arms of the L?

Yes. The live connector maintains electrical continuity through the 90-degree turn, allowing spotlights and pendants to be fitted anywhere along both track sections without needing a second power input at the corner.

Can it be used in bathrooms?

No. The IP20 rating means the connector is suitable for dry indoor locations only. For bathrooms, outdoor installations or other environments where moisture is present, an IP44 or higher rated system is required.

How is it fitted?

The connector slots into the track channel and locks with a quarter-turn twist, the same fitting method used for track heads. Installation should be carried out by a qualified electrician with the track system isolated from the mains supply.
