12V/24V LED Flex 4-Way X Connector - Single Colour 8mm

£199
The RRP is the manufacturer's recommended retail price of the item.
Limited Stock
We are an Independent UK Company
Price match. Found it cheaper? Contact us
Trade Discount Available
Description

The Knightsbridge CONX2P is a 4-way X-shaped connector for joining four runs of 8mm single-colour LED flex at a single junction point on 12V or 24V DC systems. The white ABS housing measures 24mm square and uses a click-fit mechanism to grip the flex without soldering, holding the copper contact pads against internal terminals to maintain electrical continuity across all four arms.

Designed for custom LED strip layouts where multiple flex runs need to branch from a central point, the connector suits under-cabinet lighting grids, display case installations, and retail shelf lighting where a single power feed splits into multiple directions. The IP20 rating limits use to dry indoor environments only. The connector ships with four separate brackets that clip onto the ends of the LED flex before inserting into the main X-junction body.

The Class III rating means the connector is designed exclusively for extra-low voltage DC circuits and carries no protective earth. Installation requires the LED flex to be cut at the marked copper pads, then each cut end is inserted into one of the four arms of the X-junction until the click-fit mechanism engages. The ABS construction provides dimensional stability and electrical insulation, while the white finish blends with ceiling and cabinet installations where the connector remains partially visible.

Specification
Length 24mm
Width 24mm
Projection 0.5°
Construction ABS
Finish White
Class III
IP Rating IP20
Primary Voltage 12/24V
Downloads

Product Specification Sheet

Frequently Asked

What width LED flex does this connector fit?

The CONX2P is designed for 8mm single-colour LED flex only. It will not fit 10mm RGB flex or other widths. Check the flex width before ordering to ensure compatibility.

Does it require soldering?

No. The connector uses a click-fit mechanism where the LED flex is inserted into the bracket arms until it clicks into place, holding the copper contact pads against internal terminals. No soldering or crimping is required.

Can it be used outdoors or in bathrooms?

No. The IP20 rating means the connector is not protected against moisture ingress and must only be used in dry indoor locations. For wet or outdoor environments, a higher IP-rated connector is needed.

What voltage does it support?

The connector supports both 12V DC and 24V DC LED flex systems. Ensure all connected flex runs and the power supply operate at the same voltage to avoid damage.
