QTX Q480 Power Amplifier 2 x 240W

£13399
The RRP is the manufacturer's recommended retail price of the item.
Limited Stock
We are an Independent UK Company
Price match. Found it cheaper? Contact us
Trade Discount Available
Description

The QTX Q480 is a dependable stereo amplifier delivering 2 x 240W max at 4 Ohms (2 x 120W RMS), 2 x 80W RMS at 8 Ohms. Designed for DJs, performers, and fixed installs, it includes versatile connectivity with RCA or 6.3mm jack inputs and SPK, 6.3mm jack, or 4mm binding post outputs. The 2U rackmount design with fan cooling ensures stable, long-term operation. Offering >98dB S/N ratio and low <0.5% THD, the Q480 guarantees clean, reliable sound.

Specification
Power supply 230Vac, 50Hz (IEC)
Frequency response 20Hz - 20kHz
Input connectors 6.3mm jack, RCA (L+R)
Input sensitivity 775mV, 10k Ohms
Output connectors 6.3mm jack, SPK, 4mm binding posts (L+R)
S/N ratio >98dB
THD <0.5%
Fuse rating T5A (240V) / T10A (110V)
Power max. : 4 Ohms 2 x 240W
Power rms : 4 Ohms 2 x 120W
Power rms : 8 Ohms 2 x 80W
Dimensions 482 x 300 x 88mm (2U)
Weight 6.45kg
Downloads

Product Manual

You Might Also Like

Recommended For You

    Our Reviews

    From first click to final installation, our customers share how Niori lights up their spaces. Read their words and envision what’s possible for yours.

    Featured Projects

    Step into our portfolio and see how we transform homes, restaurants, and commercial spaces and more, worldwide. Click here for a closer look at our latest projects.

    Front view of a black QTX Q480 Power Amplifier with two control knobs labeled Channel 1 and Channel 2. The rack-mountable device features vented panels and indicator lights above each knob, providing multiple input and output options in a minimalist design ideal for audio equipment racks.
