TENAX 10-20W CCT LED Gear Tray

£1499
The RRP is the manufacturer's recommended retail price of the item.
incl. VAT
Limited stock!
30 Day Returns
Flexible payment options
Description

Knightsbridge's latest innovation is the wattage and colour-adjustable LED gear trays. It reduces complexity by combining triple wattage and colour adjustments into a single gear tray. Secured to the casing* via four butterfly clips paired with the push-fit terminal block, ensures a speedy installation. The gear trays are compatible with the Tenax One and Tenax Quad range of casings.

*Casing is not included and must be purchased separately.

  • 3000K/ 4000K/ 5700K adjustable
  • 10W/ 15W/ 20W adjustable
  • Push-fit terminals with loop-in-loop-out capabilities
  • Options available: standard, emergency, self-test emergency, microwave sensor, emergency with a microwave sensor, self-test emergency with a microwave sensor, with daylight sensor, emergency with a daylight sensor
Specification
Length 235 mm
Width 235 mm
Projection 28 mm
Construction Aluminium
Class II
IP Rating IP20
Primary Voltage 230V 50Hz
Lamp Technology SMD LED
Dimmable No
L70B50 40000
Energy Rating (Class) post 2021 SLR D
CCT 3000/4000/5700 K
Light Colour CCT
Lumens 1360/1480/1405, 1905/2090/1960, 2345/2630/2415 lm
Wattage 10/15/20
Efficacy 151/147/141 lm/W
CRI >85
Driver Type Constant Current
Warranty 5
Downloads

Product Specification Sheet

Have a question?
We're here to help
Call Us

You Might Also Like

Recommended For You

    Our Reviews

    From first click to final installation, our customers share how Niori lights up their spaces. Read their words and envision what’s possible for yours.

    Featured Projects

    Step into our portfolio and see how we transform homes, restaurants, and commercial spaces and more, worldwide. Click here for a closer look at our latest projects.

    The TENAX 10-20W CCT LED Gear Tray, designed as a square circuit board, showcases a circular layout of small LED lights and includes wattage and color adjustable settings. It is labeled PB3500-CPAA and comes equipped with a push-fit terminal block, connectors, and various small electronic components against a plain white background.
