LYYT 12-24V RGB DMX Controller

£2799
The RRP is the manufacturer's recommended retail price of the item.
Limited Stock
We are an Independent UK Company
Price match. Found it cheaper? Contact us
Trade Discount Available
Description

This DMX decoder is designed to convert the universal standard DMX512/1990 into analogue signal to control either 12V or 24V RGB LED tape. This model can drive 8A/channel and it simply assigns a colour per DMX channel. DC power input and colour channel outputs are connected via screw terminals. DMX input and through connection are also via screw terminals with the start address set by side mounted DIP switches. Powered by a 12V or 24V power supply, this decoder enables 3 channel DMX control of Red, Green and Blue output

  • 3 channel DMX control for RGB colour mixing
  • 256 levels of brightness
  • Up to 8A output per channel
  • 12V or 24V operation
  • Screw terminal DMX input
Specification
Power supply 12-24Vdc
Power : max. ?288W/12V?576W/24V
Current consumption 24A max.
DMX channels 3
Output current 3 x 8A max.
Power connection Screw terminals
Output Blue, Red, Green, V+
Working temperature -20?50?
IP rating IP20
Dimensions 170 x 30 x 40mm
Weight 92g
Downloads

Product Manual

You Might Also Like

Recommended For You

    Our Reviews

    From first click to final installation, our customers share how Niori lights up their spaces. Read their words and envision what’s possible for yours.

    Featured Projects

    Step into our portfolio and see how we transform homes, restaurants, and commercial spaces and more, worldwide. Click here for a closer look at our latest projects.

    The LYYT 12-24V RGB DMX Controller is a rectangular device featuring multiple wire connection ports labeled for D+, D-, GND, and AC. The label provides details such as stock code, power supply, and output current. This white controller is compatible with DMX512/1990 standards and has mounting holes on both ends for easy installation.
